要主零件部件材料表
|
Parts
零件名稱 |
Materials
材料 |
|
Body
閥體 |
CarbonsteelStainlessSteeJ
碳鋼、不銹鋼 |
|
|
Gauze Filter Cap
濾網(wǎng)蓋 |
CarbonsteelStainlessSteeJ
碳鋼、不銹鋼 |
|
|
Filter Core Net
濾芯網(wǎng) |
Stainless Steel
不銹鋼 |
|
|
Gasker
墊片 |
Metal graphite
金屬石墨 |
|
Nominal
Diameter (DN) 公稱通徑 |
Connection
連接方式 |
Nominal
Pressure (MPa) 公稱壓力 |
Max．Allowable
TMP(℃) 最高允許溫度 |
TDG—B External Dimensions(mm)
外形尺寸 |
TDG—B External Dimensions(mm)
外形尺寸 |
|||||||||
|
L
|
H2
|
H1
|
D
|
C
|
L
|
H2
|
H1
|
H
|
D
|
C
|
||||
|
25
|
Flange
法蘭 |
PN一1.6
PN一2.5 PN一4.0 PN一6.4 |
350
|
215
|
1 65
|
1 05
|
76
|
470
|
21 5
|
1 10
|
70
|
270
|
76
|
470
|
|
32
|
230
|
1 65
|
1 05
|
76
|
470
|
230
|
1 1 5
|
75
|
280
|
76
|
470
|
|||
|
40
|
270
|
1 75
|
130
|
108
|
560
|
270
|
1 20
|
1 00
|
305
|
108
|
560
|
|||
|
50
|
270
|
1 75
|
1 30
|
1 14
|
560
|
270
|
120
|
1 00
|
305
|
1 1 4
|
560
|
|||
|
65
|
330
|
21 0
|
1 45
|
1 40
|
71 0
|
330
|
1 55
|
1 1 5
|
355
|
140
|
71 0
|
|||
|
80
|
340
|
255
|
1 50
|
1 59
|
790
|
340
|
1 75
|
135
|
405
|
1 59
|
790
|
|||
|
1 00
|
430
|
300
|
1 75
|
21 9
|
820
|
430
|
21 5
|
185
|
475
|
21 9
|
820
|
|||
|
1 25
|
480
|
355
|
1 90
|
273
|
880
|
480
|
265
|
1 95
|
545
|
273
|
880
|
|||
|
1 50
|
500
|
425
|
21 0
|
273
|
-
|
500
|
315
|
225
|
635
|
273
|
-
|
|||
|
200
|
560
|
525
|
260
|
325
|
-
|
560
|
380
|
275
|
785
|
325
|
-
|
|||
|
250
|
660
|
630
|
305
|
426
|
-
|
660
|
470
|
320
|
935
|
426
|
-
|
|||
|
300
|
750
|
830
|
365
|
478
|
-
|
750
|
630
|
360
|
1195
|
478
|
-
|
|||
