公稱壓(Mpa)
|
殼體試驗壓力(MPa)
|
密封試驗壓力(MPa)
|
調壓范圍(MPa)
|
適用介質
|
介質溫度(℃)
|
1.0
|
1.5
|
1.1
|
0.09-0.8
|
水
|
0-80
|
1.6
|
2.4
|
1.76
|
0.15-1.4
|
||
2.5
|
3.75
|
2.75
|
0.2-2.0
|
三、J145X隔膜式電動遙控閥主要零件材料:
零件名稱
|
零件材料
|
閥體 閥蓋
|
WCB
|
閥座 閥盤
|
銅合金/2Cr13
|
密封圈 O型圈
|
丁腈橡膠
|
閥桿
|
2Cr13
|
彈簧
|
50CrVA
|
缸套 活塞(活塞型)
|
2Cr13
|
膜片(膜片型)
|
夾織物丁腈橡膠
|
調節閥 球閥
|
銅合金
|
過濾器
|
不銹鋼
|
四、J145X隔膜式電動遙控閥主要連接尺寸:
DN
|
L
|
H
|
D
|
D1
|
n-d
|
||||||
1. 0MPa
|
1.6MPa
|
2.5MPa
|
1.0MPa
|
1.6MPa
|
2.5MPa
|
1.0MPa
|
1.6MPa
|
2.5MPa
|
|||
50
|
203
|
293
|
165
|
165
|
165
|
125
|
125
|
125
|
4-18
|
4-18
|
4-18
|
65
|
216
|
328
|
185
|
185
|
185
|
145
|
145
|
145
|
4-18
|
4-18
|
8-18
|
80
|
248
|
364
|
200
|
200
|
200
|
160
|
160
|
160
|
8-18
|
8-18
|
8-18
|
100
|
283
|
418
|
220
|
220
|
235
|
180
|
180
|
190
|
8-18
|
8-18
|
8-22
|
125
|
330
|
481
|
250
|
250
|
270
|
210
|
210
|
220
|
8-22
|
8-22
|
8-22
|
150
|
356
|
543
|
285
|
285
|
300
|
240
|
240
|
250
|
8-22
|
8-22
|
8-26
|
200
|
444
|
673
|
340
|
340
|
360
|
295
|
295
|
310
|
12-22
|
12-22
|
8-26
|
250
|
533
|
792
|
395
|
405
|
425
|
350
|
355
|
370
|
12-22
|
12-26
|
12-30
|
300
|
600
|
927
|
445
|
460
|
485
|
400
|
410
|
430
|
16-22
|
12-26
|
16-30
|
350
|
622
|
957
|
505
|
520
|
555
|
460
|
470
|
490
|
16-26
|
12-26
|
16-33
|
400
|
698
|
1188
|
565
|
580
|
620
|
515
|
525
|
550
|
20-26
|
16-30
|
16-36
|
450
|
775
|
1218
|
615
|
640
|
670
|
565
|
585
|
600
|
20-26
|
20-30
|
20-36
|
500
|
811
|
1256
|
670
|
715
|
730
|
620
|
650
|
660
|
20-30
|
20-33
|
20-36
|
600
|
900
|
1600
|
780
|
840
|
- |
725
|
770
|
- |
24-30
|
20-36
|
- |
700
|
980
|
1750
|
895
|
910
|
- |
840
|
840
|
- |
24-30
|
20-36
|
- |
800
|
1120
|
1900
|
1015
|
1025
|
- |
950
|
950
|
- |
24-33
|
24-36
|
- |
900
|
1120
|
2100
|
1115
|
- | - |
1050
|
- | - |
28-33
|
24-39
|
- |
1000
|
1320
|
2400
|
1230
|
- | - |
1160
|
- | - |
28-36
|
- | - |
