設計與制造 |
柱塞閥、柱塞閥截止閥、GB12235,柱塞閘閥GB12234 |
結構長度 |
國標GB12221、部標JB97、美標ANSI、B16.10 |
法蘭結構尺寸 |
JB81-59、HB5010-58、HG20592 20635、ANSI、B16.5 |
檢查和試驗 |
按GB/T13927-1992或IBJ16006-1990、API598之規定 |
閥體材料 |
適用溫度 |
適用介質 |
范圍壓力 |
鑄鋼 |
≤425℃ |
水、蒸氣、石油 |
PN1.6-10 |
不銹鋼 |
≤300℃ |
硝酸、醋酸 |
PN1.6-10 |
含鉬不銹鋼 |
≤300℃ |
氮、氫、氨、尿素 |
PN1.6-10 |
蒙乃爾 |
≤300℃ |
氫、氟、酸 |
PN1.6-10 |
鉻鉬礬鋼 |
≤600℃ |
蒸氣、石油 |
PN1.6-10 |
閥體材料 |
適用溫度 |
適用介質 |
范圍壓力 |
鑄鋼 |
≤425℃ |
水、蒸氣、石油產品 |
PN1.6-16MPa |
不銹鋼 |
≤300℃ |
硝酸、醋酸 |
通徑范圍 |
含鉬不銹鋼 |
≤300℃ |
氮、氫、氨、尿素等 |
DN15-400mm |
蒙乃爾 |
≤300℃ |
氫氟酸 |
DN |
L |
D |
D1 |
D2 |
b |
Z-φd |
H≈ |
H1≈ |
D0 |
重量 (公斤) |
15 |
130 |
95 |
65 |
45 |
14 |
4-14 |
145 |
157 |
100 |
3.5 |
20 |
150 |
105 |
75 |
55 |
14 |
4-14 |
149 |
165 |
120 |
4.4 |
25 |
160 |
115 |
85 |
65 |
14 |
4-14 |
166 |
84 |
140 |
5.6 |
32 |
180 |
135 |
100 |
78 |
16 |
4-18 |
187 |
213 |
160 |
8.5 |
40 |
200 |
145 |
110 |
85 |
16 |
4-18 |
208 |
236 |
180 |
11.0 |
50 |
230 |
160 |
125 |
100 |
16 |
4-18 |
234 |
268 |
220 |
15.0 |
65 |
290 |
180 |
145 |
120 |
18 |
4-18 |
284 |
330 |
240 |
21.0 |
80 |
310 |
195 |
160 |
135 |
20 |
8-18 |
314 |
358 |
280 |
30.0 |
100 |
350 |
215 |
180 |
155 |
20 |
8-18 |
365 |
427 |
320 |
41.0 |
125 |
400 |
245 |
210 |
185 |
22 |
8-18 |
401 |
475 |
360 |
60.0 |
150 |
480 |
280 |
240 |
210 |
24 |
8-23 |
415 |
505 |
400 |
82.0 |
200 |
600 |
335 |
295 |
265 |
26 |
12-23 |
508 |
626 |
450 |
147.0 |
250 |
650 |
405 |
355 |
320 |
30 |
12-25 |
590 |
740 |
500 |
220.0 |
300 |
750 |
460 |
410 |
375 |
30 |
12-25 |
1000 |
1160 |
560 |
290 |
350 |
850 |
520 |
470 |
435 |
34 |
16-25 |
1040 |
1210 |
640 |
450 |
400 |
914 |
580 |
525 |
485 |
36 |
16-30 |
1200 |
1400 |
720 |
725 |
DN |
L |
D |
D1 |
D2 |
b |
Z-φd |
H≈ |
H1≈ |
D0 |
重量 (公斤) |
15 |
130 |
95 |
65 |
45 |
16 |
4-14 |
145 |
157 |
100 |
3.5 |
20 |
150 |
105 |
75 |
55 |
16 |
4-14 |
149 |
165 |
120 |
4.4 |
25 |
160 |
115 |
85 |
65 |
16 |
4-14 |
166 |
84 |
140 |
5.6 |
32 |
180 |
135 |
100 |
78 |
18 |
4-18 |
187 |
213 |
160 |
8.5 |
40 |
200 |
145 |
110 |
85 |
18 |
4-18 |
208 |
236 |
180 |
12.0 |
50 |
230 |
160 |
125 |
100 |
18 |
4-18 |
234 |
268 |
220 |
16.0 |
65 |
290 |
180 |
145 |
120 |
20 |
8-18 |
284 |
330 |
240 |
22.0 |
80 |
310 |
195 |
160 |
135 |
22 |
8-18 |
314 |
358 |
280 |
32.0 |
100 |
350 |
230 |
190 |
160 |
24 |
8-23 |
365 |
427 |
320 |
46.0 |
125 |
400 |
270 |
220 |
188 |
28 |
8-25 |
401 |
475 |
360 |
65.0 |
150 |
480 |
300 |
250 |
218 |
30 |
8-25 |
415 |
505 |
400 |
92.0 |
200 |
600 |
360 |
310 |
278 |
34 |
12-25 |
508 |
626 |
450 |
165.0 |
250 |
650 |
425 |
370 |
332 |
36 |
12-30 |
590 |
740 |
500 |
250.0 |
300 |
750 |
485 |
430 |
390 |
40 |
16-30 |
1000 |
1160 |
560 |
305 |
350 |
850 |
550 |
490 |
448 |
44 |
16-34 |
1040 |
1210 |
640 |
470 |
400 |
914 |
610 |
550 |
505 |
48 |
16-34 |
1200 |
1400 |
720 |
780 |
DN |
L |
D |
D1 |
D2 |
D6 |
b |
Z-φd |
H≈ |
H1≈ |
D0 |
重量 (公斤) |
15 |
130 |
95 |
65 |
45 |
40 |
16 |
4-14 |
145 |
157 |
100 |
3.5 |
20 |
150 |
105 |
75 |
55 |
51 |
16 |
4-14 |
149 |
165 |
120 |
4.4 |
25 |
160 |
115 |
85 |
65 |
58 |
16 |
4-14 |
166 |
84 |
140 |
5.6 |
32 |
180 |
135 |
100 |
78 |
66 |
18 |
4-18 |
187 |
213 |
160 |
8.5 |
40 |
200 |
145 |
110 |
85 |
76 |
18 |
4-18 |
208 |
236 |
180 |
12.0 |
50 |
230 |
160 |
125 |
100 |
88 |
20 |
4-18 |
234 |
268 |
220 |
16.0 |
65 |
290 |
180 |
145 |
120 |
110 |
22 |
4-18 |
284 |
330 |
240 |
22.0 |
80 |
310 |
195 |
160 |
135 |
121 |
22 |
8-18 |
314 |
358 |
280 |
32.0 |
100 |
350 |
230 |
190 |
160 |
150 |
24 |
8-23 |
365 |
427 |
320 |
46.0 |
125 |
400 |
270 |
220 |
188 |
176 |
28 |
8-25 |
401 |
475 |
360 |
70.0 |
150 |
480 |
300 |
250 |
218 |
204 |
30 |
8-25 |
415 |
505 |
400 |
93.0 |
200 |
600 |
375 |
320 |
282 |
260 |
38 |
8-30 |
508 |
626 |
450 |
185.0 |
250 |
650 |
445 |
385 |
345 |
313 |
42 |
12-34 |
590 |
740 |
500 |
275 |
300 |
750 |
510 |
450 |
408 |
364 |
46 |
12-34 |
1000 |
1160 |
560 |
340 |
350 |
850 |
570 |
510 |
465 |
422 |
52 |
16-34 |
1040 |
1210 |
640 |
510 |
400 |
914 |
655 |
585 |
535 |
474 |
58 |
16-41 |
1200 |
1400 |
720 |
850 |
DN |
L |
D |
D1 |
D2 |
D6 |
b |
Z-φd |
D0 |
15 |
170 |
105 |
75 |
55 |
41 |
18 |
4-14 |
140 |
20 |
190 |
125 |
90 |
68 |
51 |
20 |
4-18 |
160 |
25 |
210 |
135 |
100 |
78 |
58 |
22 |
4-18 |
180 |
32 |
230 |
150 |
110 |
82 |
66 |
24 |
4-23 |
200 |
40 |
260 |
165 |
125 |
95 |
76 |
24 |
4-23 |
240 |
50 |
300 |
175 |
135 |
105 |
88 |
26 |
4-23 |
280 |
65 |
340 |
200 |
160 |
130 |
110 |
28 |
8-23 |
320 |
80 |
380 |
210 |
170 |
140 |
121 |
30 |
8-23 |
360 |
100 |
430 |
250 |
200 |
168 |
150 |
32 |
8-25 |
400 |
125 |
500 |
295 |
240 |
202 |
176 |
36 |
8-30 |
450 |
150 |
550 |
340 |
280 |
240 |
204 |
38 |
8-34 |
500 |
200 |
600 |
405 |
345 |
300 |
260 |
44 |
12-34 |
560 |
250 |
650 |
470 |
400 |
352 |
313 |
48 |
12-41 |
640 |
300 |
750 |
530 |
460 |
412 |
364 |
54 |
16-41 |
800 |
